The GP-60-A is a long-range reader that can detect RFID transponders from up to sixty centimetres distance.Long-range RFID readerUp to 60 cm reading rangeVery compact 21x21x2.8 cmWeather-proofRS232, RS485, Wiegand125 kHz, EM H4001/40025V to 13.5V power supplyMore Information...An internal relay allows direct connection to door openers and other systems. Use the GP-60-A to implement security and access solutions easily or use it in car parks, line production
The GP-60-A is a long-range reader that can detect RFID transponders from up to sixty centimetres distance.
Long-range RFID reader
Up to 60 cm reading range
Very compact 21x21x2.8 cm
Weather-proof
RS232, RS485, Wiegand
125 kHz, EM H4001/4002
5V to 13.5V power supply
An internal relay allows direct connection to door openers and other systems. Use the GP-60-A to implement security and access solutions easily or use it in car parks, line production facilities or container registration. Its long range even allows reading the transponder through walls and packaging. Once a transponder is correctly detected, an acoustic signal notifies users. All read data is transmitted over the serial interface to the host. The data output format is selectable, making integration into existing systems easy. You can choose among RS232, ASCII, Wiegand and magnetic card format. An open cable tail simplifies integration into existing systems. Another advantage of the GP-60-A is a variable power supply range from 5 V to 13.5 V.
The sturdy weather-proof housing is well-suited for outdoor operation at -10 to 60C.
