Honeywell 8690i Wearable UHF RFID Reader 1D & 2D Barcode Scanner Hand-Free Mobile Computer operates with Hands-Free Compact RFID mini mobile computer with UHF RFID Mobile Hands-free RFID UHF Reader with 1D & 2D barcode scanner and mobile computer UHF RFID Frequency Rangesare for UK & EU frequencies at 865-868MHz well as for USA & canada with 902-928MHz RFID frequency now available as a two-finger ring or back-of-the-hand model and weighs only
Honeywell 8690i Wearable UHF RFID Reader 1D & 2D Barcode Scanner Hand-Free Mobile Computer operates with Hands-Free Compact RFID mini mobile computer with UHF RFID Mobile Hands-free RFID UHF Reader with 1D & 2D barcode scanner and mobile computer UHF RFID Frequency Rangesare for UK & EU frequencies at 865-868MHz well as for USA & canada with 902-928MHz RFID frequency now available as a two-finger ring or back-of-the-hand model and weighs only lightweight: 211grams with robust IP54-certified rating.
Honeywell 8690i Wearable UHF RFID Reader 1D & 2D Barcode Scanner Hand-Free Mobile Computer is a compact, high-performance, hands-free mini mobile computer to help businesses improve workflow efficiency with ergonomic 8690i Wearable RFID Mini Mobile Computer delivers essential workflow information directly to the worker’s line of sight and enables input to support common workflows with a single device. Eliminating wasted motion with always-at-hand, ergonomic RFID reading and scanning drives efficiency in high frequency workflows.
Honeywell 8690i Wearable UHF RFID Reader Hand-Free Mobile Computer is a very compact mini mobile computer for hands-free scanning, ideal for fast and efficient picking, packing and sorting in warehouses, logistics and the industry. Weighing just 211 grams, the 8690i is a true lightweight which speeds up productivity in product and position identification via RFID. Compared to working with common handheld scanners, work steps are reduced by up to 66% when using the Honeywell 8690i.
Honweywell 8690i Wearable Reader Hand-Free Mobile Computer UHF RFID mini mobile computer is individually configurable for the respective area of application. Users see important information at a glance without the need for unnecessary movement - increasing efficiency and boosting productivity. Thanks to the customisable user interface, the Honeywell 8690i displays necessary instructions, plus menu navigation and selection confirmation is straightforward, via two buttons. Connect the portable RFID mini mobile computer directly to the network application via WLAN - thanks to available plug-ins, many functions are also available offline.
Industry-standard EPC Global Class 1 Gen 2, RFID reader ensures that the 8690i can read all common supply chain RFID tags.
Reduce acquisition and operations costs with the customizable line-of-sight color display, WiFi, and SDK for application development, enabling the 8690i device to support streamlined workflows as a standalone device, replacing scanner, reader, and mobile computer alternatives.
Customize to fit multiple applications with field-reconfigurable accessories that enable ring or glove mounts. Chargers are available for devices and batteries in 4 or 12 bay options for distributed or large scale consolidated deployments.
Engineered for 2,000 0.5 meter (1.6 feet) tumbles, the 8690i wearable mini mobile is built to endure rugged work environments and real-world use.
Honeywell Operational Intelligence workflow analytics to manage battery population lifecycle, ensuring uninterrupted full-shift operation; simple deployment of setting and firmware updates
Features:
Battery: 3.6 V, 3400 mAhHours of operation:
Minimum 6 hour active shift with continuous RFID reading and optical scanning every 4 seconds
Hot Swap Capability: Under typical conditions, device will remain operational for 100 seconds while replacing battery
Expected Charge Time:Battery charger: 3 hours
Device charger: 3.5 hours
WIRELESS
Radio Range: Bluetooth: 2.4 GHz to 2.5 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth® v. 5.0: Class 1; 100 m (330ft) line of sight; NFC communications to simplify pairing with host device
Advanced Model Wi-Fi: Bluetooth above plus Wi-Fi 802.11 a/b/g/n/ac, WiFi-r fast roaming, 2.4 and 5 GHz
RFID Standards: EPC Global Class 1 Gen 2/ISO 18000-6C
Antenna:Triggered ring:Field: Directed from top of device
Polarization: Linear polarized
Glove: Field: Directed from inside of wrist
Polarization: Linear polarized
UHF RFID Frequency Ranges: EU: 865-868 MHz US: 902-928 MHz
Nominal Read Range:Internal antenna: 0.6m (2 ft)Glove auxiliary antenna: 1m (3.3 ft)
Honeywell 8690i UHF RFID Reader wearable device is a compact, high-performance, hands-free mini mobile computer for your business that will help you improve workflow efficiency and reduce costs.
Hands-free Efficiency - Honeywell 8690i UHF RFID Reader wearable mini mobile computer is designed to speed frequent scanning tasks, while leaving hands free to do the job faster.
Reduce Acquisition and Support Costs - Honeywell 8690i UHF RFID Reader wearable satisfies workflows as a standalone device, replacing a mobile computer, scanner and reader. Reduce upfront costs, maintenance and infrastructure (charging) costs.
Customize to Fit Application - Honeywell 8690i UHF RFID Reader wearable has accessories to the scanner module enable a ring or glove form factor. Chargers are available for devices and batteries in 4 or 12 bay options for large or small deployments.
Built Rugged for the Real World - Honeywell 8690i UHF RFID Reader wearable is engineered for 2,000 0.5 meter (1.6 feet) tumbles, the 8690i wearable mini mobile computer is built to endure frequent impacts in fast-moving work environments.
Honeywell Operational Intelligence - Workflow analytics to manage battery population lifecycle, ensuring uninterrupted full-shift operation; simple deployment of setting and firmware updates.
Honeywell 8690i device is a compact, high-performance, hands-free mini mobile computer that will help your business improve workflow efficiency and reduce costs.
Drives streamlined workflows via a single device for many applications, replacing an RFID reader, scanner and mobile computer.
Customizable user-facing display communicates workflow instructions, while the two-button interface enables users to navigate menus and confirm selections.
Connects directly to the network application through Wi-Fi and the SDK, even enabling offline functionality via TotalFreedom™ plug-in development.
With the wearable 8690i mobile computer, you'll be able to converge common applications such as picking, packing and sorting onto a single device. This will not only improve ergonomics, it will also reduce your acquisition and operating costs when compared to wearable scanner plus mobile computer solutions.
And with non-line-of-sight RFID product and location identification, you can reduce the number of steps in your high-frequency workflows by up to 66% per transaction compared to handheld barcode scanning applications – yielding a significant increase in productivity and operational throughput.
Honeywell 8690i Wearable UHF RFID Reader Hand-Free Mobile Computer GLOVE CHARACTERISTICSStrap glove securely locates 8690i on back of hand for optimum dexterity, ergonomics, and user comfort. Secondary RFID antenna optimizes performance reading items during handling process.
Highly durable design for long lifespan, reduced consumable costs; trigger rated for 2.5MM activations.
Hygienic, non-absorbent material construction.Compatible with bare hand or conventional glove for comfort and user safety.
One size; highly adjustable at index finger, palm, and wrist. Left and right hand versions available.
The RFID mini mobile computer is also robust: it is IP54-certified and withstands 2,000 falls from 0.5 m, as well as 36 falls from 1.5 m onto concrete. A 3,400 mAh battery provides the necessary power during usage - the performance has been designed for at least a six-hour active shift. When the battery is being replaced, the 8690i remains operational for 100 seconds after the battery is removed.
The 8690i is available as a two-finger ring or as a back-of-the-hand installation on a glove. On the glove, the 8690i is securely fixed to the back of the hand - ideal for even more freedom of movement and ergonomics. Plus, 4- and 12-port charging stations are available for the batteries and the mini mobile computer.
8690i drives streamlined workflows via a single device for many applications, replacing an RFID reader, scanner and mobile computer. The customizable user-facing display communicates workflow instructions, while the two-button interface enables users to navigate menus and confirm selections. The 8690i wearable mini mobile computer connects directly to the network application through Wi-Fi and the SDK, even enabling offline functionality via TotalFreedom plugin development.
Merging common applications, such as picking, packing and sorting, onto a single device offers improved ergonomics with reduced acquisition and operating costs when compared to wearable scanner plus mobile computer solutions. Rapid RFID product and location identification can enable up to a 66% reduction in steps per transaction vs. handheld barcode scanning applications in high frequency workflows, increasing productivity and operational throughput.
Configuration options help tailor the 8690i device the end-use application. It is available (and quickly field-reconfigurable) as a two-finger ring or a back-of-hand glove mount, enabling the device to suit ergonomic and workflow requirements.
Available 4 or 12 bay chargers for devices or batteries ensure simplicity to support high volume consolidated settings or widely distributed workflows. With advanced performance to drive highly efficient workflows and durability to survive tough operating environments, the 8690i wearable mini mobile computer can add efficiency and effectiveness to even the most common tasks.
Glove CHARACTERISTICS - Strap glove securely locates 8690i on back of hand for optimum dexterity, ergonomics, and user comfort. Secondary RFID antenna optimizes performance reading items during handling process.
Highly durable design for long lifespan, reduced consumable costs; trigger rated for 2.5MM activations. Hygienic, non-absorbent material construction. Compatible with bare hand or conventional glove for comfort and user safety.
One size; highly adjustable at index finger, palm, and wrist. Left and right hand versions available.
