RFID Labels & Tags

You can now buy from a full range of RFID Labels & RFID Tags, manufactured by the top brands such as Zebra, Alien, Impinj, SMARTAC, Honeywell, The Tag factory, HID, Xerafy, Primera, SATO, Intermec by Honeywell and many more. RFID Labels and tags come in many different form factors – Labels, Tags, Inlays, Wristbands with various RFID frequencies include UHF - 860-960 MHz, HF - 13.56 MHz, LF - 125 / 134.2 KHz, BLE - 2.4Ghz. RFID Tags and Labels come in various form factors -

All-Surface RFID Tags, Embeddable RFID Tags, HF-High Frequency RFID Tags, On-Metal RFID Tags, RFID ID Cards Tags, RFID self-adhesive Labels Tags, Robust Rugged RFID Tags, Specialty RFID Tags and RFID Labels, dry and wet Inlays.

They can be applied to various surfaces - Metal and non-metal surfaces, Metal only, Non-metal only with Adhesion/Fixation/Mounting by way of – Adhesive Glue, Screw-on or rivet, weld-On or embedded.

Industrial standards/protocol supported are- ISO 15693, ISO 18000-3, ISO 18000-6C, ISO 18000-6C, ISO 17364, ISO 14443A, NFC, EPC C1G2, Bluetooth Smart, DIN 30745, EN 14803, Tag Type4 as well as ATEX EPC C1G2. Application for peak temperatures - Low ( < 212°F or < 100°C), Medium (212 - 302°F or 100-150°C), High (>302°F or >150°C). IC Chip include - Alien, Impinj, NXP, Smartrac.

Technical Specifications of Impinj RFID UHF Integrated Circuits (ICs):
UHF IC             TID     EPC         User Memory     Read Sensitivity
Impinj Monza 4QT     96 Bit     128 Bit     512 Bit     -22 dBm
Impinj Monza 4E     96 Bit     496 Bit     128 Bit     -22 dBm
Impinj Monza 4D     96 Bit     128 Bit     32 Bit         -22 dBm
Impinj Monza 4i     96 Bit     256 Bit     480 Bit     -22 dBm
Impinj Monza 5         96 Bit     128 Bit     32 Bit         -20 dBm
Impinj Monza R6     96 Bit     96 Bit     --     -22.1 dBm
Impinj Monza R6-A     96 Bit     96 Bit     --     -22.1 dBm
Impinj Monza R6-P     96 Bit     96-128 Bit*     32-64 Bit*     -22.1 dBm
Impinj Monza X         96 Bit     128 Bit     8 KBit         -21.6 dBm
Impinj M730         96 Bit     128 Bit     --         -24 dBm
Impinj M750         96 Bit     96 Bit         32 Bit         -24 dBm
Impinj M770         96 Bit     128 Bit     32 Bit         -24 dBm
Impinj M775         96 Bit     128 Bit     32 Bit         -24 dBm
Impinj M780         96 Bit     496 Bit     128 Bit     -23.5 dBm
Impinj M781         96 Bit     128 Bit     512 Bit     -23.5 dBm
Impinj M830         96 Bit     128 Bit     --         -25.5 dBm
Impinj M850         96 Bit     96 Bit         32 Bit         -25.5 dBm
