Features

- Operates effectively with a very good read range, especially when attached to metal.
- Rugged construction for high durability.
- Can be attached by screws with the help of two holes.
- Can also be provided with Adhesive tape for easy attachment.
- Flexible Read/Write Range (reader dependent).

Applications

- Used in asset tracking applications such as Equipment, Parts, Containers, railway and warehousing solutions.
- Factory automation, Automotive & Security purpose.

Chip Type:

I-Code SLIX 13.56 MHz, ISO/IEC 15693
1024 bits, organized in 32 blocks of 4 bytes each
Data retention of 50 years
Write endurance 100,000 cycles

Mechanical:

Dimension: 90 x 34 x 7mm
Hole Dia: 5 mm
Material: ABS
Colour: Blue
Weight: 21 g

Electrical:

Operating Frequency:  13.56 MHz
Operating mode: Passive (battery-less transponder)

Ingress Protection: IP68

Thermal:

Storage Temp: -40°C to +85°C
Operating Temp: -25°C to+85°C

Part Number: 216A1

Options:

Other IC type & Colour on request
